Description
Specifications
- 3.5″/2.5″ Universal drive mounts2 (included)
- Dedicated 2.5″ drive mounts4 (2 included)
- Expansion slots7
- Front interface1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button
- Total fan mounts7x 120 or 4x 140 mm and 2x 120 mm
- Front fan3x 120 or 2x 140 mm, (2x Dynamic X2 GP-14 included)
- Top fan2x 120/140 mm
- Rear fan1x 120 mm, (1x Dynamic X2 GP-12 included)
- Bottom fan1x 120 mm (requires removal of HDD cage)
- Dust filtersTop, front and bottom
- Fixed velcro strapsYes
- Cable routing grommetsYes
- Captive thumbscrewsHDD, SSD and PSU brackets
- Left side panelTempered Glass
- Right side panelSteel
Compatibility
- Motherboard compatibilityATX / mATX / Mini-ITX
- Power supply typeATX
- PSU max length200 mm (165 mm with HDD cage and front fan)
- GPU max length341 mm (360 mm without front fan)
- CPU cooler max height169 mm
- Front radiatorUp to 360/280 mm
- Top radiatorUp to 240 mm
- Rear radiator120 mm
- Bottom radiator120 mm (requires removal of HDD cage)
- Cable routing space17-28 mm
- Radiator Support – Additional DetailsMaximum radiator width: 145mm for front mounting. Maximum motherboard component height for top mounted radiator: 40 mm. For more details, consult the manual.
Dimensions
- Case dimensions (LxWxH)424 x 210 x 475 mm
- Case dimensions w/o feet/protrusions/screws412 x 210 x 455 mm
- Package dimensions (LxWxH)542 x 320 x 554 mm
- Net weight7.7 kg
- Gross weight9.3 kg
- Volume39.4 Liters
Reviews
There are no reviews yet.
