Specifications

• 3.5″/2.5″ Universal drive brackets
  3
• Dedicated 2.5″ drive brackets
  2 included, 4 positions total
• Expansion slots
  7 + 2 vertical
• Front ports
  1x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, Audio I/O
• Total fan mounts
  9
• Front fan
  3x 120/140 mm (2 x Dynamic X2 GP-14 included)
• Top fan
  3x 120/140 mm or 1x 180 mm with 165 mm hole spacing
• Rear fan
  1x 120/140 mm (1 x Dynamic X2 GP-14 included)
• Bottom fan
  2x 120/140 mm
• Dust filters
  Bottom fan + PSU, Front fans, Top panel
• Cable routing grommets
  Yes
• Fixed velcro straps
  Yes
• Tool-less push-to-lock
  Both side panels
• Captive thumbscrews
  HDD brackets, SSD brackets
• Left side panel
  Light tint tempered glass
• Right side panel
  Steel

Compatibility

• Power supply type
  ATX
• Motherboard compatibility
  EATX (up to 285 mm wide), ATX, mATX, ITX
• Front radiator
  120/240/360 mm, 140/280 mm
• Top radiator
  120/240/360 mm, 140/280/420 mm (max 35 mm motherboard component height)
• Rear radiator
  120 mm
• Bottom radiator
  120/240 mm, 140/280 mm
• PSU max length
  300 mm
• GPU max length
  440 mm with front fan mounted
• CPU cooler max height
  185 mm
• Cable routing space
  23 mm
• Vertical GPU Support (with Flex VRC-25)
  31mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling

Dimensions

• Case dimensions (LxWxH)Case dimensions (LxWxH)
  538 x 233 x 465 mm
• Case dimensions w/o feet/protrusions/screws
  530 x 233 x 448 mm
• Net weight
  10.04 kg
• Package dimensions (LxWxH)
  535 x 325 x 650 mm
• Gross weight
  11.79 kg
• Volume
  55.3 liters
